Amana K-Series 12,000 BTU PTAC Unit 208/230 Volts - 20 Amp - Electric Heat - External Thermostat - PTC123K35AXXX

No reviews yet Write a Review
Hot Pricing

Overview:

  • 12,000 BTU PTAC Unit by Amana
  • Electric Heat
  • 208/230 Volts, 20 Amp
  • Requires installation of a Wall Thermostat (Sold Separately)
Amana K-Series 12,000 BTU PTAC Unit 208/230 Volts - 20 Amp - Electric Heat - External Thermostat - PTC123K35AXXX
Compared to:
$1,229.00
$619.00

Details

This 12,000 BTU Amana (PTC123K35AXXX) PTAC air conditioner will keep your guests comfortable all year round. The PTAC AC unit offers high-quality construction and customizable settings to meet even the pickiest guests' climate control demands. This Amana 12,000 BTU PTAC AC Unit with Electric Heat uses 208/230 Volts and 20 Amps. NOTE: PWHK01G70 Thermostat Wire Harness is included with this unit. After the installation of an External Thermostat, it's always easy for users to adjust the room temperature to their preferred level of comfort.
pdfimagehttps://newros4lessmedia.s3.us-east-2.amazonaws.com/100913/Amana J_K Series Installation Instructions.pdf
pdfimagehttps://newros4lessmedia.s3.us-east-2.amazonaws.com/100913/Amana PTAC Warranty Certificate.pdf

Overview:

  • 12,000 BTU PTAC Unit by Amana
  • Electric Heat
  • 208/230 Volts, 20 Amp
  • Requires installation of a Wall Thermostat (Sold Separately)

Product Info

Air Conditioner Type:
PTAC
Manufacturer:
Amana
Manufacturer Sku:
PTC123K35AXXX
Condition:
New
Cooling BTU:
12,000 BTU
Machine Volts:
208/230
Machine Amps:
20 amp
Cord Included:
Yes
Plug Type:
NEMA 6-20
Controls:
Thermostat (External)
Heat:
Electric Heat
Heater Size (KW):
3.5 KW
Fits Standard 42" x 16" Sleeve:
Yes
Shipping Length:
47
Shipping Width:
26
Shipping Height:
21
Energy Star Certified:
No
Whole Machine - Labor Warranty:
1 Year
Compressor / Sealed System Warranty:
5 Years
Refrigerant Type:
R-410A
Remote Control:
No
Automatic Restart:
Yes
Seacoast Protection:
No
Freeze Protection:
Yes
Number of Fan Motors:
2
Fan Speeds:
2
ADA Compliant:
No
Energy Efficiency Rating (EER):
11
Sleeve Included:
No
Grille Included:
No
BTUs Heating (Nominal):
11900
Maximum Cooling Watts:
1080
Maximum Cooling Amps:
6.1
Maximum Heating Watts:
3500
Maximum Heating Amps:
15.2
Actual Cooling BTUs @ 230V:
11900
Actual Heating BTUs Heat Pump @ 208V:
9800
Actual Heating BTUs Heat Pump @ 230V:
11900
CFM (Cool/Wet Coil) - High:
330
CFM (Cool/Wet Coil) - Low:
245
